X-Mill 300
Wet & Dry Milling
High accuracy harmonic drive axis(A axis) of 360° rotation
1800w Industiral spindle, allows fast milling of hard materials like PEEK and PMMA.
Multi-function holder, for more material milling
Case presentation
Technical Data
Name | X-Mill Milling Machine |
Dimension | 730×720×620(mm) |
Net weight | Approximately 150kg |
Input voltage | Single phase AC 220V |
Max power | 2.2kw |
Spindle power | 1.5kw |
Axis quantity | 4 |
Milling range | XYZ:125/130/80mm 360° (±20) |
Milling mode | Wet and dry milling |
Max speed | 60,000 rpm |
Max feeding speed | 6000 mm/min |
Bur capacity | 6 |
Bur changing | Automatic |
Cooling | Water cooling |
Materials | Zirconia, wax,premill abutment(optional),PMMA,glass ceramic(optical) |
Milling time | Zirconia:8mins, wax:3mins,glass ceramic: 15mins,premill abutment:16mins |
